Equipment List
Working envelopes and capacities, not adjectives. If a machine you need isn't here, we don't have it.
Cutting
| Machine | Type | Qty | Working envelope | Capacity / accuracy |
|---|
| Fiber laser | Exchange-table fiber laser | 1 | 2,000 × 6,000 mm sheet | 20 mm CS / 10 mm SS |
| Plate cutting | CNC gantry flame / plasma table | 1 | — | Flame to 80 mm, plasma to 40 mm |
Forming
| Machine | Type | Qty | Working envelope | Capacity / accuracy |
|---|
| Press brake | CNC hydraulic, segmented clamps | 1 | 4,000 mm bed | 400 t |
| Plate rolls | Three-roll bending machine | 1 | 2,500 mm width | 30 mm plate, min Ø600 mm |
Welding
| Machine | Type | Qty | Working envelope | Capacity / accuracy |
|---|
| Welding bays | Screened MAG / MMA bays, fume extraction | — | Assemblies to 12,000 × 4,000 × 3,500 mm | ISO 5817 Level C |
| Overhead cranes | Single-girder EOT | 2 | — | 5 t per crane |
Machining
| Machine | Type | Qty | Working envelope | Capacity / accuracy |
|---|
| Gantry machining centres | Double-column, 5-face capable | 4 | Workpieces to 2,800 × 1,600 × 800 mm | ISO 2768-m |
| Five-axis head | Double-swivel head on the gantry | 1 | — | Simultaneous 5-axis |
| Vertical turret lathes | Single-column VTL | 2 | Ø2,000 × 1,200 mm | — |
| Vertical machining centres | 3-axis VMC | 3 | — | — |
Heat treatment & surface
| Machine | Type | Qty | Working envelope | Capacity / accuracy |
|---|
| Stress-relief furnace | In-house furnace | 1 | — | Thermal cycle charts supplied |
| Shot blasting | Blast room | 1 | 6,000 × 2,500 × 2,500 mm | Sa 2½ |
| Painting | Airless spray, C4 systems | — | — | DFT 160–320 μm |
Inspection
| Machine | Type | Qty | Working envelope | Capacity / accuracy |
|---|
| Weld NDT | UT flaw detectors + MPI yokes | — | — | Scope agreed in the ITP |
| Dimensional | Laser level, large micrometers, squares | — | To the largest workpiece | ISO 2768-m |
